| Type |
ABC POWDER
S/P |
ABC POWDER
S/P |
ABC POWDER
S/P |
ABC POWDER
S/P |
ABC POWDER
S/P |
| Capacity(kg) |
1 |
2 |
6 |
9 |
12 |
| Fire rating |
8A 34B C |
13A 55B |
27A 183B C |
34A 233B C |
43A 233B C |
| Cylinder hight(mm) |
270 |
310 |
450 |
510 |
600 |
| Cylinder out-diameter(mm) |
85 |
110 |
160 |
180 |
180 |
| Cylinder weight(kg) |
0.7 |
1.1 |
2.9 |
4.3 |
5 |
| Filled weight(kg) |
1 |
2 |
6 |
9 |
12 |
| Extinguisher weight(kg) |
2.2 |
3.7 |
9.7 |
14 |
18 |
| Range of throw(m) |
> 2 |
> 2 |
> 4 |
> 4 |
> 4 |
| Duration of discharge(secs) |
9 |
10 |
15 |
15 |
18 |
| Working pressure(at 20 ℃) |
15 bar |
15 bar |
15 bar |
15 bar |
15 bar |
| Max working pressure(bar) |
18 |
18 |
18 |
18 |
18 |
| Test pressure(bar) |
27 |
27 |
27 |
27 |
27 |
| Temperature range(℃) |
-30℃-60℃ |
-30℃-60℃ |
-30℃-60℃ |
-30℃-60℃ |
-30℃-60℃ |
| Min wall-thickness(mm) |
1 |
1.07 |
1.24 |
1.3 |
1.3 |
| Volume(L) |
1.25 |
2.5 |
7.5 |
11.2 |
13.6 |
| Material |
St12/DC01 |
St12/DC01 |
St12/DC01 |
St12/DC01 |
St12/DC01 |
| Packing size(cm) |
10x10x36 |
12x13x40 |
17x18x56 |
19x20x62 |
19x20x71 |
| BS EN3 approved |
yes﹗ |
yes﹗ |
yes﹗ |
yes﹗ |
yes﹗ |
| Price |
please click |
please click |
please click |
please click |
please click | |
